G110 with 6” x 10’ Fume Arm

We got your back. This is one powerful portable and our most popular unit by far. Super easy to set up and even easier to use!

STANDARD FEATURES:

Compressed Air Filter Cleaning, Built-In Spark Arrestance, High Performance Blower, Acoustic Silencing & Heavy Duty – All Steel Construction.

Filter Media: Nanofiber Merv 15
Air Flow (CFM): 750
Sound Level: 67 dBA
Input Power: 110V, Single Phase, 16 Amps
Motor HP: 3/4
Application: Manual Welding
Dimensions: 35” high, 22” wide, 36” deep
Includes: 6″ by 10′ Fume Arm
Minihelic Filter Gauge

G112 with 6” Flex Hose and hood

We got your back. This is one powerful portable and our most popular unit by far. Super easy to set up and even easier to use!

STANDARD FEATURES:

Compressed Air Filter Cleaning, Built-In Spark Arrestance, High Performance Blower, Acoustic Silencing & Heavy Duty – All Steel Construction.

Filter Media: Nanofiber Merv 15
Air Flow (CFM): 750
Sound Level: 67 dBA
Input Power: 110V, Single Phase, 16 Amps
Motor HP: 3/4
Application: Manual Welding
Dimensions: 35” high, 22” wide, 36” deep
Includes: 6” by 12’ Flex Duct and Hood
Minihelic Filter Gauge

G120 with 8” x 10’ Fume Arm

You asked for it, here it is. Our top of the line portable, with the unique ability to quickly change from an extra-large 8” Fume arm or dual 6” Arms, to a Back Draft or a Down Draft table! All in one powerful 1200 CFM unit, with on board compressed air tank.

STANDARD FEATURES:

Portable Unit with unique quick change-out from BackDraft to DownDraft or Fume Arms. Compressed air Pulse Cleaning System with on board tank, High Compression Filter Clamp, Slide Out Dust Tray, Built-In Spark Arrestance, High Performance Airfoil Blower, Acoustic Silencing, Heavy Duty – All Steel Construction, Suitable for Welding Stainless Steel.

Filter Media: Nanofiber Merv 15
Air Flow (CFM): 1200
Sound Level: 76 dBA
Input Power: 110V, Single Phase, 20 Amps
Motor: 1.5
Application: Manual Welding
Dimensions: 53” high, 23” wide, 31” deep
Includes: 8″ by 10′ Fume Arm

G121 with (2) 6” x 10’ Fume Arms

STANDARD FEATURES:

Portable Unit with unique quick change-out from BackDraft to DownDraft or Fume Arms. Compressed air Pulse Cleaning System with on board tank, High Compression Filter Clamp, Slide Out Dust Tray, Built-In Spark Arrestance, High Performance Airfoil Blower, Acoustic Silencing, Heavy Duty – All Steel Construction, Suitable for Welding Stainless Steel.

Filter Media: Nanofiber Merv 15
Air Flow (CFM): 1200
Sound Level: 76 dBA
Input Power: 110V, Single Phase, 20 Amps
Motor: 1.5
Application: Manual Welding
Dimensions: 53” high, 23” wide, 31” deep
Includes: (2) 6″ by 10′ Fume Arms

S100

G122 with FlexDraft Attachment

STANDARD FEATURES:

Portable Unit with unique quick change-out from BackDraft to DownDraft or Fume Arms. Compressed air Pulse Cleaning System with on board tank, High Compression Filter Clamp, Slide Out Dust Tray, Built-In Spark Arrestance, High Performance Airfoil Blower, Acoustic Silencing, Heavy Duty – All Steel Construction, Suitable for Welding Stainless Steel.

Filter Media: Nanofiber Merv 15
Air Flow (CFM): 1200
Sound Level: 76 dBA
Input Power: 110V, Single Phase, 20 Amps
Motor: 1.5
Application: Manual Welding
Dimensions: 53” high, 23” wide, 31” deep
Includes: FlexDraft attachment and Curtain

G130 with 2” x 15’ Flex Hose

Catch it right at the source. Grab this little unit, drop it next to your welder and hook it straight up to your tip-extraction welding torch. Or hook up the 15’ flex hose, to one of the handy intake hoods available. (Image shown with optional FC-VB Flared Cone Nozzle – sold separately)

STANDARD FEATURES:

Roll around High Vac Unit, Compressed Air Filter Cleaning, Built-In Spark Arrestance, High Vacuum Blower, Acoustic Silencing, Heavy Duty – All Steel Construction, Suitable for Welding Stainless Steel.

Filter Media: Nanofiber Merv 15
Max Air Flow (CFM): 160
Sound Level: 75 dBA
Input Power: 110V, Single Phase, 15 Amps
Motor HP: 2.3HP (1700W)
Dimensions: 18” high, 16” wide, 14” deep
Includes: 2” by 15’ Flex Hose
Minihelic Filter Gauge
Drop-down Handle
